Framing and Utility Plans

Braced Rafters, MWPS-72008
Rafters have 32' to 36' spans and 2' spacing.

Open PDF file and save.

Picture of layout

Laminated Arches, MWPS-72015
Bent laminated arches bent in a jig, glued and nailed. Spans are from 34', 36' and 40'

Open PDF file and save.

Picture of arches

24' Frame Utility Building, MWPS-72044
Building has concrete foundation, floor and apron and uses 6'x6' posts, 2'x8' girders and 1/2' plywood bracing.

Open PDF file and save.

Picture of building

30' Frame Utility Building, MWPS-72045
This building is designed for use as beef housing, dairy resting barn , other livestock housing, or machinery storage.

Open PDF file and save.

Picture of building framing

36' Frame Utility Building, MWPS-72046
Building is designed for use as beef housing, dairy resting barn , other livestock housing, or machinery storage.

Open PDF file and save.

Picture of building framing

40' Frame Utility Building, MWPS-72047
Building is designed for use as beef housing, dairy resting barn , other livestock housing, or machinery storage.

Open PDF file and save.

Picture of building framing

42' Wide Pole Utility Building, MWPS-72050
This building is designed for livestock housing, crop storage, machinery storage or other uses not requiring insulation.

Open PDF file and save.

Picture of building

24' Pole Utility Building, MWPS-72054
This building uses 4"x 12' and 5"x 15' pole sizes placed 16' on center. It can be used for beef housing, dairy resting barn and machinery storage.

Open PDF file and save.

Picture of building

30' Pole Utility Building, MWPS-72055
This building uses 4"x 12' and 5"x 15' pole sizes placed 16' on center. It can be used for beef housing, dairy resting barn and machinery storage.

Open PDF file and save.

Picture of building framing

36' Pole Utility Building, MWPS-72056
This building uses 4"x 12' and 5"x 15' pole sizes placed 16' on center. It can be used for beef housing, dairy resting barn and machinery storage.

Open PDF file and save.

Picture of building

40' Pole Utility Building, MWPS-72057
This building uses 4"x 12' and 5"x 15' pole sizes placed 16' on center. It can be used for beef housing, dairy resting barn and machinery storage.

Open PDF file and save.

Picture of building framing

50' Pole Utility Building, MWPS-72058
This building can be used for beef housing, dairy resting barn and machinery storage. It has concrete under poles.

Open PDF file and save.

Picture of building

24' Tilt-Up Concrete Utility Building, MWPS-72084
Building has concrete floor , pier foundation, side panels and apron.

Open PDF file and save.

Picture of building

30' Tilt-Up Concrete Utility Building, MWPS-72085
Building has concrete floor , pier foundation, side panels and apron.

Open PDF file and save.

Picture of building framing

40' Tilt-Up Concrete Utility Building, MWPS-72087
Building has concrete floor , pier foundation, side panels and apron.

Open PDF file and save.

Picture of building
